Schleif- / Poliermaschine Saphir 550 / Rubin 520 Technische Daten
| Working wheels |
ø 200 - 300 mm |
| No. of samples (single pressure) |
1-6 samples ø 50 mm |
| Single pressing force |
variable, 5-80 N |
| Central pressing force |
variable, 20-400 N |
| Connection power |
3.2 kVA |
| Drive power (base) |
0.75 kW S6/40% |
| Drive power (head) |
0.17 kW S1 |
| Speed (grinder) |
50 - 600 rpm |
| Speed (head) |
30 - 150 rpm |
| W x H x D |
560 x 550 - 650 x 660 mm |
| Weight |
~ 85 kg |
| Water connection |
1x fresh water connection R½" max. 6 bars |
Schleif- / Poliermaschine Saphir 550 / Rubin 520 Downloads
Diamant- und SIC-Schleifscheiben
Probenhalter
Produktdatenblatt Saphir 550.3 with Rubin 520.3
Produktübersicht
Saphir 550 / 560 Katalogseiten
Verbrauchsmaterialien
